Cem-FIL® 5325 | Owens Corning Composites
TALK TO AN EXPERT

PERFORMANCE FOR MINIMAL COVER

Cem-FIL® 5325 has been specially designed for the weaving of fabrics, meshes/nets, and scrims.

TALK TO AN EXPERT

Specifications and Literature

Performance Attributes

Checkmark on Clipboard Icon

PERFORMANCE

Checkmark on Clipboard Icon

PROCESSING

  • PERFORMANCE

    • Alkali-Resistant Glass*


    • Enabling meshes for high performance GRC


    • High tensile strength

  • PROCESSING

    • Excellent unwinding


    • Low level of fuzz


    • Compatible with coating and hydraulic binders


    • Good wet-out characteristics

Applications

Mesh products made from Cem-FIL® 5325 are typically used in GRC and precast concrete elements to reinforce near surface stress concentrations as well as in top screeds, mortars, stucco, and renders. The wide range of roving tex enables a large variety of meshes.

Technical Information

Technical Characteristics

LINEAR DENSITY OF ROVING (TEX)
(ISO 1889:2009)		 FILAMENT DIAMETER (µm)
(ISO 1888)		 LOSS ON IGNITION (%)
(ISO 1887:1995)		 MOISTURE (%)
(ISO 3344:1997)
320 14 0.80 0.50 max.
640 14 0.80 0.50 max.
1200 19 0.80 0.50 max.
2400 27 0.80 0.50 max.
• Direct Roving
• Electrical Conductivity: Very low
• Specific Gravity: 2.68 g/cm³
• Material: Alkali-resistant glass*
• Softening Point: 860ºC–1,580ºF
• Chemical Resistance: Very high
• Modulus of Elasticity: 72 GPa–10 x 106 psi
• Tensile Strength: >1,000 MPa >145 x 103 psi

* Our fibers are manufactured with high zirconia content in compliance with ASTM C1666/C1666/M-07, and EN 15422, and under the recommendations of PCI and GRCA.

Packaging & Storage

Cem-FIL® 5325 rovings are protected by a shrink-wrap polythene film, open at the top, which should not be removed when the product is in use. Rovings are packed on pallets. Cem-FIL® 5325 rovings should be stored away from heat and moisture, and in their original packaging. Optimum conditions are temperatures between 15°C and 35°C and humidity between 35% and 65%. If the product is stored at lower temperatures, it is advisable to condition it in the workshop for at least 24 hours before use, to prevent condensation.


Quality Standards

Cem-FIL® 5325 fibers are manufactured under a Quality Management System approved to ISO 9001.

Cem-FIL® fibers are not classified as dangerous by the Regulation 1272/2008/EC. For more information, please refer to our Safe Use Instruction Sheet.

CE-marking and Declaration of Performance as fibers for use in concrete and mortar through European Technical Assessment ETA 17/0169 for 320 to 1200 tex.

Verified Environmental Product Declaration according to ISO 14025 and EN 15804:2019 available upon request.

    Regional Availability

    Cem-FIL® 5325 is available worldwide.

    Applications

    • Buildings and Construction > Concrete > Expansion Contraction and Isolation Joints
    • Buildings and Construction > Concrete > Exposed to High Voltages
    • Buildings and Construction > Concrete > Fiber Reinforcement
    • Buildings and Construction > Concrete > Structural Strengthening
