Unifilo® 700 Series | Owens Corning Composites
Skip to main content

MAKE HIGH QUALITY PREFORM

UNIFILO® 700 Series continuous filament mats represent a large choice of tailored preforming solutions for closed mold process.

TALK TO AN EXPERT

Specifications and Literature

Performance Attributes

Customized for Multiple Needs Icon

Customized for Multiple Needs

Easy Processing Icon

Easy Processing

Enhanced Mechanical Properties Icon

Enhanced Mechanical Properties

Corrosion Resistance Icon

Corrosion Resistance

  • Easy processing

    S744, S750 products enable extra stretch and good resin flow for deeper draw applications.


    U746 product provides good stretch and excellent resin flow required in multi-layer applications.

  • Enhanced mechanical properties

    T750, T754 products provide enhanced mechanical properties in the cross-mat direction.


    U720 product provides stronger and more durable preforms. It is well suited for automated processes.

  • Corrosion resistance

    Excellent corrosion resistance with Advantex® Glass compared to standard E-glass: providing longer service life in applications facing corrosion.

Customized for multiple needs

U700 products are available with varying filament lay-out and binder contents to match up with specific customer applications.

Heavy truck - Automotive - Industrial

UNIFILO® 700 Series mats are compatible with unsaturated polyester, vinyl ester, acrylic and epoxy resins. They are designed to be preformed with the same dimensions as the final part and for use in closed mold process such as RTM (high and low- pressure injection), infusion and compression molding. Applications include heavy truck, automotive and industrial parts.

Technical Information

Availability

Unifilo® 700 Series mats are available worldwide. All products are made to order. Additional widths are available upon request by your Owens Corning contact.


Nominal Mat Weight (g/cm2) Nominal Mat Weight (oz./sq.ft.) Roll Width (cm) Roll Width (cm)
300 - 450 - 600 1.0 - 1.5 - 2.0 50 to 306 19.7 to 120.5

Packaging (Standard Reference)

Each roll is wound on a 103mm (4") internal diameter cardboard tube and wrapped with a transparent stretch film.


Nominal Mat Width(cm/ in) Roll Ø (cm/ in) Rolls per Pallet Pallet Size (cm/ in)
<=105/ 41 55/ 22 8 114x114/ 45x45
105 to 210/ 41 to 83 55/ 22 4 114x114/ 45x45
>210/ 83 55/ 22 2 to 8 Wooden Crate

Labeling

Each roll bears a label detailing the product description, product code, nominal weight, roll width, roll number and manufacture date.


Storage

It is recommended to store glass fiber products in a cool, dry area. The glass fiber products must remain in their original packaging material until the point of usage; the product should be stored in the workshop, within its original packaging, 48 hours prior to its utilization, to allow it to reach the workshop temperature condition and prevent condensation, especially during cold season. The packaging is not waterproof. Be sure to protect the product from the weather and other sources of water. When stored properly, there is no known shelf life to the product, but retesting is advised after two years from the initial production date to insure optimum performance. The Vertical rolls packaging system is designed to allow stacking of two pallets. When stacking pallets two high, care should be taken to place the top pallet gently and aligned properly; the use of a plywood interlayer (min. 6 mm thickness) is recommended. Owens Corning is not responsible for any damage resulting from stacking pallets more than two high. Wooden crates are not stackable.

    Regional Availability

    Unifilo® 700 Series mats are available worldwide.

    Applications

    • Buildings and Construction > Exterior > Architectural facades
    • Consumer Goods > Swimming Pools
    • Industrial and Corrosion
    • Infrastructure > Paving
    • Infrastructure > Road and Highway > Asphalt Pavement
    • OEM (Original Equipment Manufacturer)
    • Oil and Gas
    • Transportation > Automotive > Interior > Near-to-Engine
    • Transportation > Heavy Transportation
    • Transportation > Marine
    • Transportation > Rail and Train
