The following data was generated using PulStrand® PRO41—28 Yield (17600 Tex) on pultruded part cross-section of samples: 1 inch by 0.125 inch (25.4 mm by 3.175 mm).
| Mechanical Properties | Flexural Strength Astm D790 | Inter-laminar Shear Strength Astm D 2344 | Fiber Weight Fraction (%) | ||
|---|---|---|---|---|---|
| Flexural Strength (ksi) | Flexural Strength (MPa) | Short Beam Strength (ksi) | Short Beam Strength (MPa) | ||
| Polyester Resin | 156 | 1075 | 6.5 | 45 | 80.7 |
| Polyurethane Resin | 208 | 1431 | 12.2 | 84 | 82.1 |
| Tex | Yield | Region Available |
|---|---|---|
| 13800 | 36 | China |
| 17600 | 28 | N. America |
| 19200 | 26 | Europe, China, India |
Rovings are available in a single-end internal- pull package. Each pallet weighs about 1 ton and is packaged in bulk. Pallets are stretch-wrapped for load stability and for protection during transport. All individual packages are wrapped with Tack-Pak(TM) packaging to aid package run- out and transfer. More information is available in the Customer Acceptance Standards.
Each individual package is labeled with information including: product name, tex/yield, producing plant, and production date.
Glass fiber products should be stored in a cool, dry area. The glass fiber products must remain in their original packaging material until use; the product should be stored in the workshop, within its original packaging, 48 hours prior to its utilization, to allow it to reach the workshop temperature condition and prevent condensation, especially during cold weather. The packaging is not waterproof. Be sure to protect the product from the weather and other sources of water.
When stored properly, the product has no known shelf-life issues, but retesting is advised after three years from the initial production date to insure optimum performance.
