Windstrand® 3000 | Owens Corning Composites
Talk to an Expert

Lighter Blades, Higher Performance

Windstrand® 3000 combines high weaving efficiencies and increased tensile Modulus at 0° for lighter blades and reliable performance. Blades utilizing Windstrand® 3000 are capable of operating in extreme environments due to its optimized design.

Talk to an Expert

Specifications and Literature

Performance Attributes

Checkmark on Clipboard Icon

Reliable Performance

Checkmark on Clipboard Icon

Lighter Blades

Checkmark on Clipboard Icon

Stronger Blades

  • Lighter Blades

    3-6% blade weight reduction

  • High weaving efficiency

    High weaving efficiency for stronger blades

  • High Performance

    • 0° fiber Modulus greater than 88 GPa
    • Enhanced 90 ̊ properties
    • Operation at increased Fiber Volume Fraction (FVF) levels

Technical Information

Technical Characteristics (Single-End Roving)


PRODUCT OFFERINGS WINDSTRAND® 3000 NOMINAL FILAMENT DIAMETER (μm) LINEAR DENSITY TEX (G/KM) ISO 1889 SOLIDS (%) ISO 1887
300 Tex 13 300 ± 15 0.65 ± 0.20
600 Tex 17 600 ± 30 0.55 ± 0.12
1200 Tex 17 1200 ± 60 0.55 ± 0.12
2400 Tex 17 2400 ± 120 0.55 ± 0.12

Applications

Optimized design for wind turbines in all on-shore and off-shore locations.

  • High-performance designs of Spar Cap, Shell and Root.
  • Production of longer and lighter blades help in especially low wind areas.


Packaging (Standard Reference)

Rovings are available in a single-end internal-pull package. Each pallet weighs approximately 1 ton. Pallets are stretch-wrapped for load stability. All doffs are wrapped with Tack-PakTM for protection and to aid package run-out and transfer. Full doffs are approximately 19 kg (40 lb.) and they can be packaged in bulk or Creel-Pak® format.


Standard Package:

  • Cylindrical bobbin without tube, Outside Diameter (OD) ± 270mm, height 260-300mm.
  • Partial bobbins have smaller diameter.
  • Max bobbin weight must not exceed 19kg.
  • Bobbin covered by a Tack-Pack™ film.

Pallet:

  • Size: 1150x1150mm, 4 ways entry.
  • 16 bobbins (ma x OD) per layer. Pallets are 3 to 4 tiers high.
  • Pallet is stretch-wrapped.

Identification:

  • Bobbin label (each bobbin).
  • Four pallet labels, one on side of the pallet.

    Regional Availability

    Owens Corning® High-Modulus Glass is globally available in WINDSTRAND® single-end roving form factor. Please, contact your Owens Corning representative for information on TEX (yield) ranges and resin systems compatibility in your region.

    Applications

    • Wind Energy > Root
    • Wind Energy > Shear Web
    • Wind Energy > Shell
    • Wind Energy > Spar Cap
    • Wind Energy > Trailing Edge

    Get in Touch

    Reach out to our team of experts. We're ready to answer your questions on product specifications, technical requirements, and beyond.
