ProPINK® Wall Insulation System | Owens Corning Insulation

PROPINK® Complete Blown-in Wall System is an alternative to roll or batt insulation in walls, ceilings or other enclosed cavity applications, for both new construction and retrofit projects.

Complete system includes:

  • PROPINK® Loosefill Insulation,
  • PROPINK® Complete Non-Woven Fabric.
  • INSPECT-R® Density Gauge
Download data sheet
PROPINK® Loosefill Insulation package, Made in Canada seal

Features

  • Will not significantly settle over time, ensuring installed thermal resistance is maintained.
  • Non-combustible
  • Phenol-formaldehyde, perlite, and vermiculite free
  • Non-corrosive
  • Dry installation application
  • High performance fiberizing technology

Thermal Performance

Stated R-value is achieved by installing the minimum required number of bags per 92.9 net m2 (1,000 net ft2 ) at a thickness not less than the label minimum thickness and minimum m2 (ft2 ) weight. Failure by the installer to provide both the required number of bags and at least the minimum density will result in lower insulation R-value. Nominal net weight of insulation is 31.4 lbs.

Installation

Only registered ProPINK® Wall Product System Installers certified by Owens Corning may install this product. Please contact local Owens Corning Area Sales Manager for certification.

Certifications and Sustainable Features

  1. Recycled content certified by SCS Global services. Current information available at owenscorning.com/ en-ca/corporate/sustainability/product-sustainability/product/transparency-standards; see Recycled Content Certification Canada
  2. GREENGUARD Certified products are certified to GREENGUARD standards for low chemical emissions into indoor air during product usage. For more information, visit ul.com/gg
  3. Environmental Product Declaration (EPD) has been certified by UL Environment*

Technical Information

Performance Criteria

PROPERTY

VALUE

TEST METHOD

Compliance

CCMC Evaluation Listing No. 13240-R
Type 5

CCMC
CAN/ULC-S702.1

Additional Performance Information

PROPERTY

VALUE

TEST METHOD

FIRE

Non-combustibility (complies)

CAN/ULC-S114

See Application Chart for thermal resistance
values

CAN/ULC-
S702 .1-14-AMD1

Flame Spread 0; Smoke Developed <5

CAN/ULC-S102.2

MOISTURE

Fungi Resistance (complies)

ASTM C1338

Water Vapour Sorption <5% by weight at 49 °C (120 °F), 95% R.H.

ASTM C1104

CORROSION

Corrosion of Steel (pass)

C167

Technical Information

  • Deliver products in their original packages, and store in enclosed shelter.
  • Packaging is not UV resistant. Shelter unused packages from the elements.
  • Stated thermal resistance is achieved by fastening the ProPINK® fabric such that the stated thickness is achieved and the minimum amount of product is installed per 92.9 net m2 (1,000 net ft2 ). The Inspect-R™ density gauge is recommended for controlling the amount product installed.
  • Owens Corning does not recommend or approve blending or adding additional materials or adhesives to this product during installation. Owens Corning will accept no responsibility or liability when the product is not installed in accordance with the product label and installation instructions.
  • To prevent fire or overheating of recessed light fixtures maintain building, electrical, gas and oil safety code required clearances between the insulation and heat emitting devices, such as fuel burning appliances, chimneys, pipes, ducts and vents to these appliances of at least 51 mm (2") and recessed light fixtures of at least 76 mm (3").
  • When installing PROPINK® Loosefill Insulation in a thermal or acoustical retrofit application, it is absolutely critical that the enclosed cavity crews have a general knowledge of construction and framing principles and a full understanding of the blowing equipment.
  • As manufactured, fiberglass insulation is resistant to mold growth. However, mold growth can occur on building materials, including insulation, when it becomes contaminated with organic material and when water is present. To avoid mold growth on fiberglass insulation, remove any water that has accumulated and correct or repair the source of that water as soon as possible. Insulation that has become wet should be inspected for evidence of residual moisture and contamination, and any insulation that is contaminated should be promptly removed and replaced.

Technical Services Available

For Canadian Technical inquiries, please contact our technical team at owenscorning.ca/contacttech.


Environmental and Sustainability

Owens Corning is a worldwide leader in building material systems, insulation, and composite solutions, delivering a broad range of high-quality products and services.

Owens Corning is committed to driving sustainability by delivering solutions, transforming markets, and enhancing lives. More information can be found at owenscorning.ca or owenscorninglibrary.ca.


Disclaimer of Liability
Technical information contained herein is furnished without charge or obligation and is given and accepted at recipient’s sole risk. Because conditions of use may vary and are beyond our control, Owens Corning makes no representation about, and is not responsible or liable for the accuracy or reliability of data associated with particular uses of any product described herein. SCS Global Services provides independent verification of recycled content in building materials and verifies recycled content claims made by manufacturers.
For more information, visit www.SCSglobalservices.com. LEED® is a registered trademark of the U.S. Green Building Council.

Notes
For additional information, refer to the Safe Use Instruction Sheet (SUIS) found in the SDS Database via sds.owenscorning.com.
Certification logos, Made in Canada seal

Applications

  • Ceilings
  • Walls
