Automotive - marine - Industrial
M705 mat is designed for use with unsaturated polyester, vinyl ester resin systems in hand lay-up applications including automotive parts, boats, chemical tanks and pools.
Chopped Strand Mat
FOR HAND LAY-UP IN COMPLEX MOLDS
M705/M705X1
FOR HAND LAY-UP IN COMPLEX MOLDSHIGH PERFORMANCE LOW RESIN CONSUMPTION
M705 chopped strand mat represents a compelling solution to hand lay up high glass content and thin laminates balanced with good mechanical properties.
TALK TO AN EXPERTSpecifications and Literature
Material Safety Data (SDS, SUIS) (1)
Performance Attributes
Process Efficiency
Balanced Performances
Enhanced Service Life
- Easy handling & moldabilityOptimized chop length mix provides good confirmability to complex contoured molds.
- Process efficiencyFast wetting and quick air release help reduce the labor required to roll out the part.
- Balanced performancesModerate impregnation speed reduces resin consumption, resulting in thinner laminate with high glass content, and improved mechanical properties.
- Enhanced service lifeCompared to standard E-glass, Advantex® glass helps with enhanced service life in applications facing corrosion.
Resources
BE MORE PRODUCTIVE AND EFFICIENT | M705X1
Technical Information
Availability
M705 is available in Europe and in Asia. Additional weights and widths are available upon request by your Owens Corning contact.
| Nominal Mat Weight (g/cm2) | Roll Width (cm) |
|---|---|
| 225 - 300 - 375 - 450 - 600 | 95 - 104 - 125 |
Packaging & Labeling
Each roll is wound on a 76mm cardboard tube and placed inside a polyethylene bag and cardboard box. The boxed product is then placed vertically on a wooden pallet and shrink-wrapped for stability and protection.
Each roll bears a label detailing the product description, product code, nominal weight, roll width, roll number and date of manufacture.
| Nominal Mat Width (cm) | Roll Diameter (cm) | Rolls Per Pallet | Pallet Size (cm) |
|---|---|---|---|
| 95 -104 -125 | 30 | 12 | 127 x 97 |
Storage
Unless otherwise specified, it is recommended to store glass fiber products in a cool, dry area. Ideal conditions are at a temperature between 10°C and 35°C and a relative humidity between 35% and 85%. The glass fiber products must remain in their original packaging material until the point of usage. If the storage temperature is below 15°C, it is recommended that the product be stored in the workshop, within its original packaging, at least 24 hours prior to use to help prevent condensation. The packaging is not waterproof. Be sure to protect the product from the weather and other sources of water. When stored properly, the product can be used up to 2 years from the date of manufacture, and retesting is advised after 1 year from the initial production date to insure optimum performance.
Regional Availability
M705 and M705X1 are available in Europe and in Asia.
Applications
- Chemical
- Consumer Goods > Other Open or Closed Mold
- Consumer Goods > Swimming Pools
- Industrial and Corrosion
- OEM (Original Equipment Manufacturer)
- Oil and Gas
- Pipes and Tanks
- Transportation > Automotive > Interior > Semi-Structural
- Transportation > marine
