Continuous Insulation

STANDOUT PERFORMANCE DESIGNED TO BLEND IN

Owens Corning® Thermafiber® RainBarrier® Dark™* continuous insulation semi-rigid products are produced with a bonded black facing that is designed for exceptional performance in rainscreen and cavity wall construction applications. Thermafiber® RainBarrier® Dark™ is the same continuous insulation you have come to know and trust from Owens Corning® Thermafiber® but offers camouflaging behind open-joint facade systems and eliminates the material and installation costs associated with an additional masking layer. Thermafiber® RainBarrier® Dark™ insulation provides thermal control, fire-resistive characteristics, acoustical control, and the ability to drain water from a wall cavity. All Thermafiber® RainBarrier® products are non-combustible, vapour permeable, and are easy to fabricate and install.

*Latest RainBarrier® products combine the benefits of RainBarrier® 45 and RainBarrier® HD as of April 2024.
Product Announcement

Features

  • Black facing provides camouflaging behind open-joint façade systems
  • Mold-resistant, non-deteriorating, and inorganic as tested to ASTM C1338
  • Repels and drains water
  • UV-resistant
  • Helps conserve energy and reduce greenhouse gas emissions
  • Saves time and money by eliminating secondary veils and other camouflaging methods
  • Factory-applied veil gives installers flexibility without rigidity
  • Mineral wool is non-combustible as tested to CAN/ULC-S114
  • Mineral wool board product contains a minimum of 70% recycled content
  • Contributes to credits in several green building programs, such as LEED® and Green Globes®

Standards, Codes Compliance

  • CAN/ULC-S702.1, Standard for Mineral Fibre Thermal Insulation for Buildings, Type 2
  • ASTM C612, Mineral Fibre Block and Board Thermal Insulation, Types IA, IB, II, III, IVA, IVB

Installation

Thermafiber, Inc. recommends mechanical attachment of Thermafiber® RainBarrier® insulation products. See Owens Corning publication “Thermafiber® RainBarrier® Insulation Guide - Canada” (Pub. No. 600060) for more information. The types of fastener, method, and frequency are to be determined by the installer for the specificity of the project and approved by the project design team.

Certifications and Sustainable Features

  • Verified by ICC-ES to contain a minimum of 70% recycled content. See ICC-ES Evaluation Report VAR-1025 at icc-es.org. Recycled Content pertains to insulation only.
  • Environmental Product Declaration (EPD) has been certified by UL Environment. For more information, visit ul.com/epd.

Performance Attributes

DARK VEIL

FIRE RESISTANCE

MOISTURE MANAGEMENT

THERMAL COMFORT

Technical Information

Performance Criteria

PROPERTY

VALUE

TEST METHOD

COMPLIANCE

CCMC Evaluation Listing No. 14060-L
Type 2

CCMC
CAN/ULC-S702.1

Additional Performance Information

PROPERTY

VALUE

TEST METHOD

CORROSION

Corrosion of Steel, Aluminum, and Copper (PASS)

ASTM C665

Stress Corrosion - Austenitic Stainless Steel (PASS)

ASTM C795

FIRE

Complies

CAN/ULC-S114

Non-combustible

ASTM E136

Flame Spread 20, Smoke Developed 5

CAN/ULC-S102

Flame Spread 20, Smoke Developed 15

ASTM E84

Smoulder Resistance - Mean Mass Loss Pass (≤ 2%)

CAN/ULC-S129

STABILITY

Linear Shrinkage <2% @ 650°C (1,200°F)

ASTM C356

MOISTURE

Fungi Resistance (Complies)

ASTM C1338

Water Vapor Permeance - 1432 ng/Pa.s.m2 - 2850 ng/Pa.s.m2 (25 perm - 50 perm)

ASTM E96

Water Vapor Sorption - Absorbs 0.06% by volume

ASTM C1104

UV TESTING

Complies; acceptable change in black colour after UV exposure

ICC-ES AC38 Section 4.1.2 UV Exposure with ASTM D224
Color Evaluation

Acoustical Performance

THICKNESS

125 HZ

250 HZ

500 HZ

1000HZ

2000 HZ

4000 HZ

NCR

TEST METHOD

51 mm (2")

0.36

0.79

1.15

1.04

1.01

1.04

1.00


ASTM C423

76 mm (3")

0.70

1.07

1.24

1.13

1.07

1.08

1.15

102 mm (4")

1.03

1.25

1.20

1.05

1.05

1.08

1.15

Technical Data

NOMINAL DENSITY

RSI /25.4 MM @ 24ºC M2•K/W

R-VALUE/INCH @ 75ºF HR•FT2•ºF/BTU

TEST METHOD

96 kg/m3 (6.0 pcf)

0.74

4.2

ASTM C518

Availability

THICKNESS3

STANDARD DIMENSIONS4

51 mm - 203 mm (2" - 8")

406 mm x 1219 mm (16″ x 48″), 610 mm x 1219 mm (24″ x 48″)

3 Thicknesses are available in 13 mm (½") increments.
4 Custom sizes are available upon request.

Technical Services Available

For Canadian Technical inquiries, please contact our technical team at owenscorning.ca/contacttech.


Environmental and Sustainability

Owens Corning is a worldwide leader in building material systems, insulation, and composite solutions, delivering a broad range of high-quality products and services.

Owens Corning is committed to driving sustainability by delivering solutions, transforming markets, and enhancing lives. More information can be found at owenscorning.ca or owenscorninglibrary.ca.


Disclaimer of Liability
Technical information contained herein is furnished without charge or obligation and is given and accepted at recipient’s sole risk. Because conditions of use may vary and are beyond our control, Owens Corning makes no representation about, and is not responsible or liable for, the accuracy or reliability of data associated with particular uses of any product described herein. Owens Corning reserves the right to modify this document without prior notice.
LEED® is a registered trademark of the U.S. Green Building Council.
Green Globes® is a registered trademark of Green Building Initiative, Inc.

Notes
For additional information, refer to the Safe Use Instruction Sheet (SUIS) found in the SDS Database via sds.owenscorning.com.
CERTIFICATION LOGO

Applications

  • Walls
